Irregular glass edging machine

It features a horizontal structure and is composed of a forward feeding and positioning system; four tray suction and rotating mechanisms; four suction cups for gripping; eight grinding heads for grinding; a water circulation system; and an electrical control system.
  • Brand:

    Ruilong
  • Color:

    Customized
  • Shipping Port:

    Shanghai
  • Lead Time:

    one month
  • Warranty:

    1 year
  • Size Range:

    customized
  • Processing Range:

    Irregular glass
Product Details

Configuration:

1. Material conveying motor: Delta servo

2. Material gripping and translation motor: Delta servo

3. Material suction cup: Domestic silicone

4. Material translation guide rail: Taiwan TBI

5. Rotary suction cup: Silicone

6. Rotary motor: Delta servo

7. Negative pressure pump: High-quality domestic

8. Chamfering motor: Yutong private servo (high-speed)

9. Chamfering wheel: Conical wheel, Shenzhen

10. Water pump: 180W, domestic

11. Support frame: Aluminum profile

12. Frame: Square tube + steel plate welding

13. PLC + touch screen: Delta series

14. Program: Ruilong self-made

15. Cable: Flexible cable

16. AC contactor: Chint

17. Proximity switch: Xinling Electric

Parameters:

1. Workstations: Four workstations, four rotating pallets; each workstation has two sets of chamfering motors + conical grinding heads

2. Gripping speed: 0--30 meters/minute

3. Rotation speed: 0-30 rpm (depending on product size and shape)

4. Chamfering wheel speed: 0-1500 rpm

5. Efficiency: Approximately 15-17 seconds per 4 pieces (based on 150*150mm glass). (Efficiency may vary depending on glass size.)

6. Processing range: 100*100-200*200mm (Customized)
